TP-Link EAP225-Outdoor AC1200 Gigabit Outdoor Access Point
₨21999.00
- AC1200 outdoor AP — 867 Mbps on 5 GHz
- IP65 weatherproof, -30°C to +70°C rated
- 200 m+ / 300 m+ long-range outdoor coverage
- Gigabit PoE with adapter & wall/pole kit included
- Description
- Reviews (0)
Description
Overview
The TP-Link EAP225-Outdoor AC1200 Gigabit Outdoor Access Point is a weatherproof access point built for courtyards, warehouses, schools, hotels and farms where indoor Wi-Fi simply cannot reach. It delivers dual-band AC1200 wireless — 867 Mbps on 5 GHz plus 300 Mbps on 2.4 GHz — through two detachable omnidirectional antennas, with long-range coverage rated at 200 metres or more on 2.4 GHz and 300 metres or more on 5 GHz in open outdoor conditions. A single Gigabit Ethernet port carries both data and power, so the unit can sit on a wall or a pole far from any power socket.
Its IP65-rated enclosure keeps dust and water jets out, it is rated to operate from -30°C to +70°C, and it carries lightning and ESD protection for exposed installations. A dedicated high-power amplifier and professional antennas, combined with 802.11ac Wave 2 MU-MIMO, push a stable signal much further than a typical indoor access point. It can be managed centrally with other Omada access points, or run standalone.

Key Benefits
- True outdoor design: IP65 weatherproof enclosure, -30°C to +70°C range and lightning/ESD protection.
- Long-range coverage: 200 m+ on 2.4 GHz and 300 m+ on 5 GHz in open conditions.
- Power over one cable: Gigabit PoE port supports 802.3af PoE and 24V passive PoE, adapter included.
- Flexible mounting: Wall or pole mounting kit included.
- Omada central management: One controller for mesh, seamless roaming and the Omada app.
- Detachable antennas: Two omnidirectional antennas can be replaced to suit a site requirement.
- Stable multi-user performance: Wave 2 MU-MIMO, beamforming, band steering and airtime fairness.
Detailed Features of the TP-Link EAP225-Outdoor AC1200 Gigabit Outdoor Access Point
The 2.4 GHz band reaches further and passes through obstacles better, which is why TP-Link rates it at 200 metres or more outdoors, while the faster 5 GHz band is rated at 300 metres or more in open line-of-sight conditions. These are outdoor range figures: walls, trees, interference and client quality all reduce real range. Mount the unit high, clear of obstructions, with antennas vertical. The two dual-band omnidirectional antennas spread signal evenly in all directions.
On the wireless side, 802.11ac Wave 2 MU-MIMO lets the access point talk to several clients at once instead of serving them strictly one by one, which matters when a group of visitors all join the same outdoor network. Beamforming concentrates signal towards each connected device, band steering moves capable devices onto the faster, less crowded 5 GHz band, and airtime fairness stops a single slow legacy device from hogging the channel. Omada Mesh lets access points connect wirelessly where running a cable is impractical, and seamless roaming (802.11k/v) hands a moving device to the strongest access point without dropping calls.
Installation is deliberately practical. The unit is slim — 214.9 x 46 x 26.7 mm for the main unit, excluding antennas and mounting kit — and light at 0.17 kg, so it mounts neatly on a wall bracket or straps to a pole. A PoE switch can power it over the data cable, or the included passive PoE adapter can power it from a nearby indoor socket, with runs up to 100 metres. A waterproof rubber insert seals the cable entry, and shielded cable grounding is recommended outdoors. Management includes standalone setup, the Omada app, and full controller management.
- AC1200 dual-band Wi-Fi: 867 Mbps on 5 GHz plus 300 Mbps on 2.4 GHz, Wave 2 MU-MIMO.
- IP65 weatherproof enclosure: Dust-tight, protected against water jets, with lightning/ESD protection.
- Long-range antennas: 2 detachable omni antennas, 2 x 3 dBi on 2.4 GHz and 2 x 5 dBi on 5 GHz.
- Gigabit PoE port: 1 x Gigabit port, 802.3af PoE and 24V passive PoE; adapter included.
- Omada Mesh and roaming: Self-healing mesh and 802.11k/v seamless roaming.
- Wide temperature range: -30°C to +70°C, maximum power 10.5 W.
- Guest and security controls: WPA/WPA2, captive portal, MAC authentication and access control.
Pair it with indoor coverage from the TP-Link EAP723 ceiling access point, browse all access points, and add a home router such as the Archer AX53 as the indoor gateway for the same network.
Technical Specifications
| Specification | Details |
|---|---|
| Model | TP-Link EAP225-Outdoor |
| Wi-Fi Standard | Wi-Fi 5 (IEEE 802.11ac Wave 2, backwards compatible with 802.11a/b/g/n) |
| Wireless Speed | AC1200: 867 Mbps on 5 GHz + 300 Mbps on 2.4 GHz |
| Ethernet Port | 1 x Gigabit Ethernet port (RJ45), PoE in |
| PoE Support | 802.3af PoE and 24V passive PoE; passive PoE adapter included |
| Antennas | 2 detachable omnidirectional antennas: 2 x 3 dBi (2.4 GHz), 2 x 5 dBi (5 GHz) |
| Coverage | 200 m+ on 2.4 GHz, 300 m+ on 5 GHz (outdoor, open conditions) |
| Weatherproofing | IP65-rated enclosure; lightning and ESD protection |
| Operating Temperature | -30°C to +70°C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Dimensions | 214.9 x 46 x 26.7 mm (main unit, without antennas and mounting kit) |
| Weight | 0.17 kg (main unit) |
| Power Consumption | Maximum 10.5 W |
| Wireless Features | MU-MIMO, beamforming, band steering, airtime fairness, load balance, Omada Mesh, seamless roaming (802.11k/v) |
| SSIDs | Up to 16 SSIDs (8 per band) |
| Security | WPA/WPA2-Personal, MAC-based authentication, captive portal authentication, access control |
| Management | Omada Software Controller, Omada Hardware Controller, Omada Cloud-Based Controller, Omada app, standalone web management |
| Mounting | Wall mount and pole mount (kits included) |
Ideal Users
- Homes with courtyards: Cover seating areas, garage and garden without running power outside.
- Schools and hostels: Playground and parking coverage with indoor access points.
- Warehouses and factories: Yard and loading-bay coverage that survives dust, heat and rain.
- Hotels and venues: Guest Wi-Fi for outdoor seating and lawns with captive portal login.
- Farms and outdoor sites: Long-range links across open ground where indoor equipment would fail.
- System integrators: A standard Omada outdoor unit for multi-site deployments.
What’s in the Box
- TP-Link EAP225-Outdoor AC1200 Access Point (1)
- Passive PoE adapter (1)
- Power cord (1)
- Waterproof rubber insert (1)
- Mounting kit (1)
- Detachable antennas (2)
- Installation guide (1)
FAQs
Q1: Is the EAP225-Outdoor really weatherproof?
A: Yes. It carries an IP65 rating, meaning it is dust-tight and protected against water jets, and it is rated from -30°C to +70°C. It is designed for permanent outdoor installation, not just sheltered use.
Q2: How do I power it if there is no socket outside?
A: Over the Ethernet cable. Use a PoE switch, or use the included passive PoE adapter indoors: the adapter sends power down the same cable that carries data, for runs up to 100 metres.
Q3: What range can I actually expect?
A: TP-Link rates it at 200 m+ on 2.4 GHz and 300 m+ on 5 GHz in open conditions; walls, trees and interference reduce real range, so mount it high with clear line of sight.
Q4: Can it work on its own, or do I need an Omada controller?
A: Both. It works standalone with web setup for a single outdoor zone, and it joins Omada controller management, mesh and seamless roaming when you have several Omada access points.
Q5: Does it support Wi-Fi 6 or WPA3?
A: No. This is a Wi-Fi 5 (802.11ac) access point with WPA/WPA2 security. If you need Wi-Fi 6 or WPA3 indoors, pair it with a Wi-Fi 6 router or a newer Omada access point for the indoor network.
Q6: Can the antennas be replaced?
A: Yes. The two omnidirectional antennas are detachable, so other compatible antennas can be fitted for a specific site requirement.
Why Buy from NexGenShop
When you buy the TP-Link EAP225-Outdoor AC1200 Gigabit Outdoor Access Point from NexGenShop, you get a 100% genuine, brand-new unit sourced through official channels, tested before dispatch, packed securely and shipped quickly anywhere in Pakistan with courier tracking. Pre-sales technical guidance is free, with safe payment options and responsive after-sales support. Follow our latest deals and new arrivals on Facebook and Instagram. For dependable TP-Link networking backed by a store that knows the technology, NexGenShop is the safe choice.













Reviews
There are no reviews yet.
