Description

Overview

The TP-Link TL-MR100-Outdoor 4G Router takes Wi-Fi beyond your walls. It is a weatherproof 4G LTE router built to live outside — on a rooftop, a courtyard wall, a farmhouse, a construction site or a shop front — and turn a mobile SIM card into reliable Wi-Fi exactly where no wired line can reach. Where indoor routers lose signal behind concrete, this unit sits out in the open and shares the strongest mobile signal with up to 32 devices.

Its headline numbers: 4G LTE downloads up to 150 Mbps and uploads up to 50 Mbps, paired with 300 Mbps Wi-Fi on 2.4 GHz. The IP65 enclosure resists dust and water jets, it works from -30°C to +60°C, and it carries 6kV lightning and 15kV ESD protection — hardening that matters for a device that lives outdoors. Power is flexible too: it runs on a 12V DC adapter or over Power over Ethernet, so one cable can carry data and power where no socket exists.

Key Benefits

• Wi-Fi where wires cannot go: A weatherproof 4G router for courtyards, rooftops, farms, construction sites and outdoor businesses — internet from a SIM card alone.
• Built for harsh weather: IP65 dust and water protection, -30°C to +60°C operation, 6kV lightning protection and 15kV ESD protection.
• Fast 4G sharing: Downloads up to 150 Mbps and uploads up to 50 Mbps over LTE, with 300 Mbps Wi-Fi shared with up to 32 devices.
• Flexible PoE or DC power: Power it from a 12V DC adapter, a passive PoE adapter, or an 802.3af/at PoE switch — one cable can carry power and data.
• Mount it anywhere: Pole, wall or window mounting kits are included, so you can position the router for the best mobile signal.
• Plug-and-play setup: Insert a nano SIM and power on — then manage everything from the Tether app or web interface.
• Signal LEDs at a glance: The signal LEDs show reception strength on the unit itself, so you can find the best mounting spot first.

Detailed Features of the TP-Link TL-MR100-Outdoor 4G Router

The TL-MR100-Outdoor starts with dependable 4G connectivity. Its LTE modem supports download speeds of up to 150 Mbps, paired with fast 300 Mbps Wi-Fi on the 2.4 GHz band (IEEE 802.11b/g/n), and it simply needs an activated SIM card without a PIN lock to get started. Two detachable LTE antennas — kept vertical for the best LTE performance — pull in the mobile signal, and the router shares it with up to 32 devices. It also works as a standard wireless router through its 100 Mbps WAN/LAN port (PoE In).

Durability is the real reason to choose this model over an indoor router. The IP65-rated enclosure resists dust and water, the operating range of -30°C to +60°C covers cold northern winters and the hottest summer rooftops, and the ±6kV lightning protection and ±15kV ESD protection guard the electronics against storms and static discharge. Before mounting outdoors, secure the waterproof cover so cables pass through the waterproof rubber slots. Power and mounting are equally flexible: the router supports IEEE 802.3af/802.3at PoE as well as 12V DC, and you can strap it to a pole, screw the bracket to a wall, or stick the bracket to a smooth, clean, dry window.

• 4G LTE outdoor connectivity: Download up to 150 Mbps and upload up to 50 Mbps over LTE, with 300 Mbps Wi-Fi for up to 32 devices.
• IP65 weatherproof enclosure: Dust-resistant and water-resistant housing for permanent outdoor installation.
• Extreme temperature range: Reliable operation from -30°C to +60°C, with storage rated from -40°C to +70°C.
• Surge and static protection: ±6kV lightning protection and ±15kV ESD protection for exposed outdoor positions.
• Three mounting options: Pole mounting with straps, wall mounting with bracket and screws, and adhesive window mounting.
• PoE and DC power: 12V/1A DC, 24V/0.5A passive PoE, or 44–57V/0.35A 802.3af PoE, plus a 10-metre Ethernet cable in the box.
• Easy management and security: Tether app and web interface with parental controls, WPA/WPA2 encryption, SPI firewall, and IP and MAC binding.

Pair the TL-MR100-Outdoor with our range of 4G routers for indoor mobile-internet options, browse outdoor routers and access points, and see TP-Link routers for the full home and business range at NexGenShop.

Technical Specifications

Specification	Details
Model	TP-Link TL-MR100-Outdoor
4G LTE Speed	Download up to 150 Mbps, upload up to 50 Mbps
Mobile Networks	4G FDD-LTE and TDD-LTE, 3G DC-HSPA+/HSPA/UMTS
Wi-Fi Speed	300 Mbps on 2.4 GHz (Wireless N)
Wireless Standards	IEEE 802.11b/g/n, 2.4 GHz
Connected Devices	Up to 32 devices
Weatherproofing	IP65 waterproof and dustproof enclosure
Operating Temperature	-30°C to +60°C
Protection	±6kV lightning protection, ±15kV ESD protection
Antennas	2× detachable LTE antennas
Ports	1× 100 Mbps WAN/LAN port (PoE In), 1× DC power port
SIM Slot	1× nano SIM card slot
Power Supply	12V/1A DC; 24V/0.5A passive PoE; 44–57V/0.35A 802.3af PoE
Mounting	Pole mounting, wall mounting, window mounting (kits included)
Operating Modes	3G/4G Router mode, Wireless Router mode
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Network Security	DoS protection, IPv4 SPI firewall, IP and MAC address binding
Management	Web interface, TP-Link Tether app
Protocols	IPv4, IPv6
Dimensions (W × D × H)	226.6 × 100 × 54.7 mm

Ideal Users

• Rural homes and farmhouses: Reliable Wi-Fi where no wired broadband exists, with the router mounted high for the best mobile signal.
• Courtyards and outdoor seating: Cafes, restaurants and guesthouses that need Wi-Fi outside the main building.
• Construction sites and temporary setups: Fast, deployable internet for site offices and events without waiting for a fixed line.
• Warehouses and godowns: Outdoor-rated coverage between buildings, powered over a single PoE cable.

What’s in the Box

• TP-Link TL-MR100-Outdoor 4G LTE Outdoor Router unit
• 2× detachable LTE antennas
• 10-metre RJ45 Ethernet cable
• PoE adapter
• AC power cord
• Window, pole and wall mounting kits
• Quick installation guide

FAQs

Q1: Is the TL-MR100-Outdoor really safe to leave outside in the rain?
A: Yes — it carries an IP65 rating for dust and water resistance and is designed for permanent outdoor use. Just secure the waterproof cover properly, with cables routed through the waterproof rubber slots.

Q2: How do I power it if there is no socket on the roof or pole?
A: Use Power over Ethernet: the included PoE adapter (or an 802.3af/at PoE switch) sends power and data over a single Ethernet cable. A 12V DC adapter option is also available.

Q3: What SIM card does it need?
A: A nano SIM card with an active data package. TP-Link notes the SIM must be activated and without a PIN lock — if yours is PIN-locked, follow the installation guide’s unlocking instructions first.

Q4: How many devices can it handle, and how fast is it?
A: Up to 32 devices, with LTE downloads up to 150 Mbps and uploads up to 50 Mbps, plus 300 Mbps Wi-Fi. Real speeds depend on signal strength and network load.

Q5: Can I mount it on a window instead of drilling holes?
A: Yes. The box includes an adhesive window-mounting bracket — TP-Link recommends a clean, smooth, dry surface, firm pressure for at least 10 seconds, and avoiding installation on a wet or rainy day.

Q6: Does it work as a normal router too, or only on 4G?
A: Both. It works as a 3G/4G router on the mobile network and as a wireless router through its WAN/LAN port, managed from the Tether app or a web browser.
